Model 73032
MMCX PLUG R/A SEMI-RIGID, RG402
Model 73032 MMCX PLUG R/A SEMI-RIGID, RG402
Snap-on coupling and micro-
miniature size for fast connect
and disconnect where space is
limited
Features
?
?
DC - 3 GHz bandwidth.
50% smaller than MCX connectors.
?
Connectors allow rotation of 360 ? for layout
Specifications
?
?
?
flexibility.
Non-slotted contact design for low RF leakage.
Meets CECC 22340 .
Perfect for applications where space, weight,
Impedance
Frequency Range
Working Voltage
50 ?
DC - 3 GHz
170 Vrms max.
performance and ease of assembly are required.
Materials
Dielectric Withstanding
Voltage
500 Vrms
?
?
?
?
Body is machined brass with gold plating.
Center contacts – Plug is gold plated Phosphor
bronze and Jack is gold plated beryllium copper.
High quality PTFE insulators.
Crimp Ferrules are gold or nickel plated copper.
VSWR
Center / Outer contact
resistance
Number of insertions
1.3 max
0.01 / 0.005 ?
500 cycles minimum
Ordering Information
Model: 73032
Description: MMCX PLUG R/A SEMI-RIGID, RG402
Insulation resistance
Temperature Range
> 500 M ?
-55 ? C to 155 ? C, -67 ?
F to 311 ? F
USA: Sales: 800-490-2361
Technical Support: technicalsupport@pomonatest.com
Fax: 425-446-5844
Europe: 31-(0) 40 2675 150 International : 425-446-5500
All dimensions are in inches. Tolerances (except noted): .xx = ±.02” (.51 mm),
.xxx = ± .005” (.127 mm). All specifications are to the latest revisions.
Specifications are subject to change without notice. Registered trademarks
are the property of their respective companies.
D2003462 REV 001
Where to Buy: www.pomonaelectronics.com
Copyright ? 2007 12/18/2007
